Product Features:
1, working time: continuous ultrasonic mode.
2, the whole machine structure: using high quality SUS316 plate stainless steel welding composition. The welding is firm and beautiful; no water leakage, the welding place is polished.
3, Transducer: Using Ilsan piezoelectric ceramic chip of Korea, it can work for long time under different temperature; imported bonding technology, ensure the transducer can work for a long time without falling off.
4, ultrasonic generator: adopt international leading technology, adopt IGBT module, SCM technology, stable working condition, bigger and stronger output power, have over-voltage, over-current, output short circuit and other protective measures.
This product support non-standard custom, can provide design drawings and cleaning program.The electrolytic ultrasonic cleaning system of blue whale double tank mould is composed of ultrasonic generating system, electrolytic circuit system, circulating filter system, special electrolytic cleaning agent and water-based antirust agent. The first tank is a cleaning tank and the second tank is a rinsing tank.
Product Scope:
1, mold type: injection mold, instrument precision mold, connector mold, precision seal mold, stamping mold, molding mold, etc. .
2, mold gas residue layer, high temperature formed sulfide, fire plastic residue, toner residue, mold surface oxide, as well as a variety of mold rust stains, oil stains, etc. .
How it works: use the die or workpiece to be cleaned as the cathode (just put it into the cleaning frame) , and use the standard electrode bar as the anode. Oxygen is produced at the anode and hydrogen is produced at the cathode by the action of electrolyzing water. During the operation, a large amount of hydrogen gas is produced on the surface of the work piece, which makes the dirt decompose and peel off quickly from the surface of the work piece. Carry on impact blasting to the dirt on the work piece, make the dirt to peel off automatically. At the same time, a special cleaning solution 102C is used to make the dirt decompose rapidly after sufficient chemical reaction. In this way, even if it is difficult to clean parts such as the mold internal groove, groove, horn, hole, bite flower and other complex parts, will be cleaned clean, the mold from the inside to the outside show a brilliant metallic luster. Wash out of the mold, rinse clean with water, and then steel special water-based anti-rust Agent Immersion. The antirust agent can quickly remove moisture from the mold surface and form a protective layer on the mold surface. It can be preserved or reprocessed after air-drying. Remanufacturing does not produce carbides that adhere to the mold.
product Scope:
1, mold type: injection mold, instrument precision mold, connector mold, precision seal mold, stamping mold, molding mold, etc. .
2, mold gas residue layer, high temperature formed sulfide, fire plastic residue, toner residue, mold surface oxide, as well as a variety of mold rust stains, oil stains, etc.
1、Determine the model
You can choose model through consultation. You can also understand the specifications and parameters and choose the model through the website. Our company can customize according to customer requirements. Welcome to the factory for inspection.
2、Inquiry
You can use telephone, online chat, messages, e-mail and other ways to get price and delivery term from sales manager.
3、Sign the contract
With product details and payment methods.
4、Payment
Payment will be made in accordance with the terms of the contract. Timely delivery will be arranged after payment.
5、Acceptance
When you receoved the machine, please check whether the outer packaging and goods are damaged. Also check the product model and quantity, as well as accessories. If the above happens, please take photos and contact with the sales staff.
6、After-sales service
1. Provide door-to-door installation and commissioning, technical personnel free guidance training;
2. After receiving feedback, we will give you response within 12 hours. We will come back to you with the solution within 36 hours;
3. We promise warranty for 18 months and provide to life-long maintenance. So you don’t need to worry about the after sales.
